Power Transformers - EDCOR Electronics Corporation

Power Transformers

Power transformers for tube amplifier, solid state equipment, design, testing and development.

Filters

Filters
299 products
Sort by
Sort by
Reference image Schematic
XPWR189 - 580V@120mA CT, 6.3V@3.25A CT, 6.3V@1A, & 5V@2A
From $196.00 CAD
Reference image Schematic
XPWR168 - 275V@125mA CT & 13V@900mA CT
$154.00 CAD
Reference image Schematic
XPWR166 - 275V@800mA, 120V@60mA, 90V@60mA, 30V@2A, & 10V@3.5A
$262.00 CAD
Reference image Schematic
XPWR165 - 400V@50mA CT & 12.6V@2A
$146.00 CAD
Reference image Schematic
XPWR164 - 460V@60mA CT, 6.3V@3A CT, & 6.3V@1A CT
$152.00 CAD
Reference image Schematic
XPWR148 - 750V@400mA CT & 460V@40mA CT
$250.00 CAD
Reference image Schematic
XPWR146 - 200V@250mA & 6.3V@4.5A
$159.00 CAD
Reference image Schematic
XPWR144 - 760V/640V@200mA CT, 6.3V@3.5A CT, & 5V@3A
$237.00 CAD
Reference Image Schematic
XPWR123 - 650V@70mA CT, 6.3V@2A CT, & 5V@2A
From $163.00 CAD
Reference image Schematic
XPWR113 - 700V@150mA CT & 6.3V@5A CT
$189.00 CAD
Reference image Schematic
XPWR109 - 700V@175mA CT & 6.3V@4A
$218.00 CAD
TBPWR-LV1 - multi tapped 20V (10-7.5-5-3.15-2.5-0 0-2.5-3.15-5-7.5-10)@4A CT. TBPWR-LV1 - multi tapped 20V (10-7.5-5-3.15-2.5-0 0-2.5-3.15-5-7.5-10)@4A CT.
TBPWR-LV1 - multi tapped 20V (10-7.5-5-3.15-2.5-0 0-2.5-3.15-5-7.5-10)@4A CT.
$186.00 CAD
TBPWR-CV1 - matching line power transformer for 240V, 230V, 220V@1.5A or 120V, 117V, 115V, 100V@3A TBPWR-CV1 - matching line power transformer for 240V, 230V, 220V@1.5A or 120V, 117V, 115V, 100V@3A
TBPWR-CV1 - matching line power transformer for 240V, 230V, 220V@1.5A or 120V, 117V, 115V, 100V@3A
$235.00 CAD
TBPWR-MV1 - multi tapped 100V (50-40-30-20-10-0 0-10-20-30-40-50)@3A CT. TBPWR-MV1 - multi tapped 100V (50-40-30-20-10-0 0-10-20-30-40-50)@3A CT.
TBPWR-MV1 - multi tapped 100V (50-40-30-20-10-0 0-10-20-30-40-50)@3A CT.
$266.00 CAD
LVP12.6-3 (12.6V@3A CT) LVP12.6-3 (12.6V@3A CT)
LVP12.6-3 (12.6V@3A CT)
$80.00 CAD
Reference image Schematic
XPWR096 - 670V@200mA CT w/70V bias, 6.3V@4A, 6.3V@4A, & 6.3V@2A CT
$232.00 CAD
Reference Image Schematic
XPWR094 - 170V@250mA & 12V@2.5A CT
$146.00 CAD
Reference image Schematic
XPWR093 - 500V@300mA CT, 6.3V@7A CT, & 5V@5A
$261.00 CAD
Reference Image Schematic
XPWR085 - 170V@250mA & 6.3V@2.5A CT
$146.00 CAD
Reference image Schematic
XPWR060 - 730V@120mA CT, 6.3V@3A CT, & 5V@2A
$192.00 CAD
Reference Image Schematic
XPWR055 - 250V@100mA, 24V@500mA, & 9V@2.5A
$161.00 CAD
Reference image Schematic
XPWR049 - 570V@220mA CT, 6.3V@2.9A, & 5V@6A
$212.00 CAD
Reference image Schematic
XPWR034 - 290V@150mA, 15V@2A, & 6.3V@2A
$169.00 CAD
Reference image Schematic
XPWR032 - 800V@150mA CT, 12.6V@600mA, 6.3V@4A, & 5V@3A
From $219.00 CAD
